ENJOY THE BEST OF BOTH WORLDS

You can have it all. Energy performance. Stunning style. ThermaArc hinged doors offer the elevated energy efficiency of double glazing with the style, class and quality of a thermally broken aluminium frame. Live your dream, in comfort.

ThermaArc Hinged Door

Maximum visual impact

The ThermaArc thermally broken hinged doors are designed with functionality in mind, available in a variety of opening styles and configurations to suit your specific architectural aesthetic.


ThermaArc Hinged Door Spec Sheet

ThermaArc Hinged Door

Design Flexibility

Open in, open out, side lite, high lite options for design flexibility.

FINISHES

With Trend's extensive palette of colours you’re sure to find exactly the right hue to express your individual vision.

Standard Range

  • Monument
    • Finish: Matt
  • Surfmist
    • Finish: Matt
  • Pearl White
    • Finish: Gloss
    • Finish Group: Standard Range
    • Lead Time: Lead time may differ between states. Please contact your local Trend team to confirm.
  • Ultra Black
    • Finish: Matt
    • Finish Group: Standard Range
    • Lead Time: Lead time may differ between states. Please contact your local Trend team to confirm.

ThermaArc Hinged Door

Finishing details can take any design to a whole new level and that’s especially true of door and window hardware.
  • Hinge Door Lever Handle
    • Finish: Brushed Nickel
    • Other finishes available: Black

GLASS OPTIONS

A range of glazing options are available to improve comfort, acoustics, security, and privacy.
  • Security

    Security

    If safety and protection are priorities, we offer a wide range of performance glass options to meet your requirements. There are two types of Grade A safety glass available. Grade A safety glass is harder to break and offers greater security against accidental injury, attempted break-ins and severe weather conditions.

    If safety and protection are priorities, we offer a wide range of performance glass options to meet your requirements. There are two types of Grade A safety glass available. Grade A safety glass is harder to break and offers greater security against accidental injury, attempted break-ins and severe weather conditions.

    Features:Safety And Security

    Glass Options:Double Glazing, Single Glazing

  • Serenity

    Serenity

    In busy, urban environments, noise is constant. There is an increasing need to reduce unwanted noise from road traffic, trains and aircraft to create a more comfortable living environment, promote a healthier sleep, reduce stress, and improve concentration. By choosing an appropriate glass for your specific location, you can significantly reduce the amount of ambient noise that penetrates your home.

    In busy, urban environments, noise is constant. There is an increasing need to reduce unwanted noise from road traffic, trains and aircraft to create a more comfortable living environment, promote a healthier sleep, reduce stress, and improve concentration. By choosing an appropriate glass for your specific location, you can significantly reduce the amount of ambient noise that penetrates your home.

    Features:Acoustics

    Glass Options:Double Glazing, Single Glazing

  • Comfort

    Comfort

    Australia has some of the harshest sunlight in the world. Maintaining a comfortable indoor environment is difficult, when temperatures rise and fall during the day and between seasons. To improve your overall comfort and well being there are a range of glazing options which allow you to improve your home’s insulation, reducing both your carbon footprint and your energy consumption.

    Australia has some of the harshest sunlight in the world. Maintaining a comfortable indoor environment is difficult, when temperatures rise and fall during the day and between seasons. To improve your overall comfort and well being there are a range of glazing options which allow you to improve your home’s insulation, reducing both your carbon footprint and your energy consumption.

    Features: Energy Efficiency

    Glass Options: Double Glazing, Single Glazing

  • Privacy

    Privacy

    The privacy range of glazing options allows for high level light transmittance, while obscuring the view from outside. Different levels of obscurity are available and the range can be toughened or laminated to provide a Grade A safety. Ideal for bathrooms, bedrooms, front entry doors or any area you want to block from prying eyes.

    The privacy range of glazing options allows for high level light transmittance, while obscuring the view from outside. Different levels of obscurity are available and the range can be toughened or laminated to provide a Grade A safety. Ideal for bathrooms, bedrooms, front entry doors or any area you want to block from prying eyes.

    Features:Privacy

    Glass Options:Double Glazing, Single Glazing

Specifications

Sill options
Open in or open out
Maximum frame
3000mm high
Maximum panel
2620mm high x 1120mm wide
Glazing
24mm Double glazing only
BAL rating
BAL40
Seal type
Vinyl wrapped foam seal
Screen options
Flyscreen and barrier screens
Double glazed Uw range
2.0 – 3.1
Double glazed SHGC range
0.17-0.52
Fenestration
Hinge Door
